Product Description
Main Features:
This machine is mainly used to thresh corn which could complete fresh corn separating work by one time and it is the best small size corn threshing machine. It has many advantages of simple compact structure, and light weight, convenient operation and maintenance, high productivity and low power consumption. It also can be matched with diesel engine to work.
Product Description:
This machine is mainly used to thresh corn which could complete fresh corn separating work by one time and it is the best small size corn threshing machine. It has many advantages of simple compact structure, and light weight, convenient operation and maintenance, high productivity and low power consumption. It is very popular by ordinary household in mountain or hill areas.
Technical Parameters
| Model | 5TY-32-140 |
| Structure type | Whole feeding roll cylinder |
| Matched power | YL90-2 Single phase, double value capacitor motor Or diesel engine 165F/170F |
| Rated Power(kW) | 1.5 |
| Rated Speed (r/min) | 2800 |
| Overall Dimensions (L*W*H) (mm) | 610*520*840 |
| Net weight (kg) | 41 |
| Feeding Type | Axial and whole feeding |
| Feeding Table Dimensions (L*W)(mm) | 300×330 |
| Feeding Table height(mm) | 120 |
| Roll Cylinder Type | Rib strip type single roller |
| Roll Cylinder Size (D*L) (mm) | φ140*320 |
| Roll Cylinder Speed (r/min) | 1500 |
| Kind of Concave | Fence type |
| Sieve Size (L*W*H)(mm) | 335*250 |
| Fan Type | Centrifugal type |
| Diameter of fan (mm) | 100 |
